Features

1.    MF04 series instrument: 4 big LED display0-100%LED bar display output ,

2.    Accuracy: (Max±0.5% fus or± 1)≤±1 digit

3.    TC input,clients can set TC input(K,E,J,T.N)by keyboard,but can not used for RTD input type.Pt100 input type controller can not be used for TC input type and Cu50 type. Cu50 input type controller can not be used for TC input type and Pt100 type.

4.    As usual, controllers were set as out1(heating) before leaving factory, of course, users can select out1(cooling)

5.    PID control: As usual, controllers have PID control before leaving factory, with Auto-tuning function

6.    ON/OFF Control: Set CrL=OF1 or OF2,it will be changed as on/off control. Check manual"6.3 parameter CrL " .  Position difference is HYS.
